Window & door systems
Four aluminium platforms covering commercial, semi-commercial and high-quality residential projects. Every order is made to size, double glazed with toughened argon-filled units as standard.
Commercial 100 (C101) Series
101.6 × 50 mm frame, thermally broken (TB101) or non-thermally-broken. Fixed, awning, sliding, casement, sashless & double-hung windows; sliding, stacking and hinged doors (P35/P45).
Specifications →
Commercial 150 Series
Window wall system (fixed/awning/casement) and HD2T/HD3T sliding doors up to 3000 H × 4000 W.
Specifications →
80 Series Bi-fold
C101-P65 bi-fold door up to 3000 H × 6000 W and R73 bi-fold window.
Specifications →
Residential 68 (R68) Series
Fixed, awning and sliding windows; sliding, stacking and hinged doors.
Specifications →Range overview
| Series | Frame | Configurations | Max size |
|---|---|---|---|
| Commercial 100 (C101) | 101.6 × 50 mm | Fixed, awning, sliding, casement, sashless, double-hung windows; sliding, stacking, hinged doors (P35/P45) | — |
| Commercial 150 | 152.4 mm (C150 sliding door) | Window wall: fixed, awning, casement; HD2T/HD3T sliding doors | Sliding doors 3000 H × 4000 W |
| Semi-commercial 80 | — | C101-P65 bi-fold door, R73 bi-fold window | Bi-fold door 3000 H × 6000 W |
| Residential 68 (R68) | — | Fixed, awning, sliding windows; sliding, stacking, hinged doors | Custom |
Glazing
| Type | Options |
|---|---|
| Standard double glazed (IGU) | 5 mm toughened / 12 mm argon / 5 mm toughened · 6 / 12 Ar / 6 · 5 / 9 Ar / 5 |
| Toughened single | 6, 8, 10, 12 mm |
| Laminated | 8.76, 10.76, 11.52 mm |
| Coatings & tints | Low-E, clear, obscure, grey tint |
All toughened glass is Grade A safety glass; double glazed units are argon filled. Glass to AS 1288 & AS 2208; IGUs to AS/NZS 4666.
Powder-coat colours
Indicative colours only — screen colours vary. Ask for physical powder-coat samples.
Flyscreen options
- Stainless steel mesh
- Heavy-duty stainless steel mesh
- High-quality alloy mesh
- Fibreglass mesh
Installation options
- Timber reveal
- Subsill / subhead & angles
- Subframe
- 35 mm fin
Download the company brochure (PDF) or request AS 2047 test reports for certification.
Send us your plans. We'll come back with a square-metre quote.
Fully custom sizes, shop drawings for sign-off and free technical support from quote to delivery.
